Mode Locked Lasers

Keywords: Mode locked, fiber laser, fs, femto-second, 532nm, 1064nm

May 04, 2022 View: 942 Data Sheet

The Femtosecond Mode Lock Fiber Laser is a compact, high-reliability laser featuring an all-fiber design (no bulk optics) with a center wavelength of 1030 nm at an average output power of 10mW, repetition rate of 25 MHz with pulse duration of 600 fs.

Online submission 15671598018 info@SintecLaser.com

STC Series Mode Locked Lasers

1. 532nm Mode-locked Picosecond Laser Series

Superior beam quality, best reliability, mode-locked picosecond pulsed laser, pulsed duration could be less than 20ps. Housed in compact packages, are the perfect choice for design in and integration into OEM instrumentation and systems and also for end user applications in research and development.

Applications:

Raman spectroscopy; Marking, Carving; Material processing; Astronomy; Scientific research; Optical instrument

Mode-locked Type:

	Wavelength(nm)	Output power(mW)	Pulse duration(ps)	Rep. rate(MHz)	Operating mode	Transverse mode
STC-PS-R-532	532	1-3000	<20	48±1	Mode-locked	TEM00
STC-PS-HR-532	532	1-2 W	~15@500kHz2 W	100-1000kHz	Mode-locked	TEM00

Fiber Laser Type:

	Wavelength(nm)	Output power(mW)	Pulse duration(ps)	Rep. rate(MHz)	Operating mode	Transverse mode
STC-FL-532-PS	532	1-150	<10	20-80 (Fixed)	Mode-locked	TEM00
STC-FL-532-Pico	532	1-1000	100-900	0.1-80 (variable)	Pulsed	TEM00

Diode Pumped Laser Type:

	Wavelength(nm)	Output power(mW)	Pulse duration(ps)	Rep. rate(MHz)	Operating mode	Transverse mode
STC-DPS-532-Pico	532	2-10 W	<50 ps	0.1-10 MHz	Pulsed	TEM00

2. 1064nm Mode-locked Picosecond Laser Series

Applications:

Raman spectroscopy; Marking, Carving; Material processing; Astronomy; Scientific research; Optical instrument

Mode-locked Type:

	Wavelength(nm)	Output power(mW)	Pulse duration(ps)	Rep. rate(MHz)	Operating mode	Transverse mode
STC-PS-RL-1064	1064	1-1000	~15 @10 kHz1 W	1-10kHz	Mode-locked	TEM00
STC-PS-HR-1064	1064	1-10 W	~15@500kHz10W	100-1000kHz	Mode-locked	TEM00
STC-PS-R-1064	1064	1-10 W	<20	48±1	Mode-locked	TEM00
STC-PS-Seed-1064	1064	1-300	<20	80±1	Mode-locked	TEM00
STC-Macro/ Micro-1064-P	1064	10 W	Macro 160 μs	Micro~100MHz	Mode-locked	TEM00

Fiber Laser Type:

	Wavelength(nm)	Output power(mW)	Pulse duration(ps)	Rep. rate(MHz)	Operating mode	Transverse mode
STC-FL-1064-PS	1064	1-2000	<10	20-80 (Fixed)	Mode-locked	TEM00
STC-FL-1064-Pico	1064	10-5000	100-900	0.1-20 (variable)	Pulsed	TEM00
